Stock Original CSBX1809-6R8M 6.8uH 18.5A 4.7mOhm High Current Power Inductor CSBX 1809 Series Shielded Wirewound Inductor
Outline:
1. Flat wire winding, achieve a low DC resistance.
2. Magnetic shielded structure: excellent resistance to electro magnetic interference(EMI)
3. Soft saturation makes them ideal for VDR/VRM applications
Features:
1. Core material: Composite
2. Core and winding loss:
3. Environmental: RoHS, Reach compliant ,Halogen free
4. Weight:15.20g
5. Moisture Sensitivity:Level (MSL) 1 (unlimited floor life at <30°C / 85% relative humidity).
6. Operating temperature range: -50℃~+150℃ (including coil’s self temperature rise)
7. Storage temperature range: -50℃~+150℃
Application:
1.Rraphic cards/ industrial conputers
2.DC /DC converters/Motherboards/Filter
3.High current switching regulators/Polyphase-switching regulators
