CSBL1809-150M CSBL1809-150MCT CSBL1809-150 15uH Shielded Wirewound Inductor Tolerance 20% Rating 14A for DC DC Converters
Package/Enclosure 19.3 x 18.2 x 8.9mm
Inductance 15uH
Tolerance 20%
Current Rating 14A
Outline:
▪ Flat wire winding, achieve a low DC resistance.
▪ Magnetic shielded structure: excellent resistance
to electro magnetic interference(EMI)
▪ Soft saturation makes them ideal for VDR/VRM applications
Features：
▪ Core material: Composite
▪ Core and winding loss:
▪ Environmental: RoHS, Reach compliant ,Halogen free
▪ Weight:15.20g
▪ Moisture Sensitivity:Level (MSL) 1
(unlimited floor life at <30°C / 85% relative humidity).
▪ Operating temperature range: -50℃～+150℃
(including coil’s self temperature rise)
▪ Storage temperature range: -50℃～+150℃
Application：
▪ Rraphic cards/ industrial conputers
▪ DC /DC converters/Motherboards/Filter
▪ High current switching regulators/Polyphase-switching regulators
